MOD-FPMD
The Peerless-AV Modular Mounts Line features a full range of products that can fulfill multiple requirements from a limited number of SKUs. With the universality of the components, configure your own perfect custom flat-panel display or projector mounting solution for any application. The Modular Mount Line was developed with the professional AV installer in mind. Designed around a 2" (50mm) diameter pole, the line is ideal for new projects as well as for upgrading existing installations. The MOD-FPMD mount is the perfect solution for mounting displays back-to-back installed using the Modular Series Line of mounts.
No pricing available. Call for Quote.
Product Datasheet
Product Name
Peerless-AV® Back-to-Back Display Mount For Modular Series Flat Panel Display Mounts
Peerless-AV® Single Display Mount For Modular Series Flat Panel Display Mounts
Peerless-AV® Modular Dual Pole Tilt Box For one display
Peerless-AV® Modular Series Dual-Pole Free Standing Floor Plate For wood or concrete floors
Peerless-AV® Modular Dual Pole Tilt Box For two back to back displays
Minimum Screen Size Supported
10" (25.40 cm)
10" (25.40 cm)
46" (116.84 cm)
46" (116.84 cm)
46" (116.84 cm)
Maximum Screen Size Supported
75" (190.50 cm)
65" (165.10 cm)
90" (228.60 cm)
90" (228.60 cm)
90" (228.60 cm)
Maximum Load Capacity
170 kg
99.79 kg
95.71 kg
191.42 kg
191.42 kg
Mounting Pattern
200 x 200
-
200 x 200
Features
This display size range is simply a guideline for product selection. Displays larger than the screen size range may still be compatible as long as they fall within the VESA® pattern and max weight of the Peerless-AV® product.
Certifications:
The Peerless-AV Modular Mounts Line features a full range of products that can fulfill multiple requirements from a limited number of SKUs. With the universality of the components, configure your own perfect custom flat-panel display or projector mounting solution for any application. The Modular Mount Line was developed with the professional AV installer in mind. Designed around a 2" (50mm) diameter pole, the line is ideal for new projects as well as for upgrading existing installations. The MOD-FPMD mount is the perfect solution for mounting displays back-to-back installed using the Modular Series Line of mounts.
General Information | |
|---|---|
| Manufacturer | Peerless Industries, Inc |
| Manufacturer Part Number | MOD-FPMD |
| Manufacturer Website Address | http://www.peerless-av.eu.com |
| Brand Name | Peerless-AV® |
| Product Series | MOD-FPMD |
| Product Model | MOD-FPMD |
| Product Name | Back-to-Back Display Mount for Modular Series Flat Panel Display Mounts |
| Marketing Information | The Peerless-AV Modular Mounts Line features a full range of products that can fulfill multiple requirements from a limited number of SKUs. With the universality of the components, configure your own perfect custom flat-panel display or projector mounting solution for any application. The Modular Mount Line was developed with the professional AV installer in mind. Designed around a 2" (50mm) diameter pole, the line is ideal for new projects as well as for upgrading existing installations. The MOD-FPMD mount is the perfect solution for mounting displays back-to-back installed using the Modular Series Line of mounts. |
| Packaged Quantity | 1 Unit |
| Product Type | Mounting Bracket |
Product Information | |
|---|---|
| Device Supported |
|
| Maximum Load Capacity | 170 kg |
| Minimum Screen Size Supported | 10" (25.40 cm) |
| Maximum Screen Size Supported | 75" (190.50 cm) |
| Features |
|
| Mount Pattern | Universal |
| Minimum Tilt Angle | -5° |
| Maximum Tilt Angle | 20° |
| Maximum Rotate Angle | 360° |
| Mount Function | |
Physical Characteristics | |
|---|---|
| Color Family | Black |
| Product Color | Black |
| Finishing | Powder Coated |
| VESA Mount Compatible | Yes |
| Mounting Pattern |
|
| Height | 12.98 cm (5.11") |
| Width | 22.38 cm (8.81") |
| Depth | 12.98 cm (5.11") |
| Weight (Approximate) | 2.04 kg |
2 x Flat Panel Screens
Miscellaneous | |
|---|---|
| Package Contents |
|
| Application/Usage | Pole |
| Indoor/Outdoor | Indoor |
| Compatibility | 2 x Flat Panel Screens |
| Certifications & Standards | RoHS, TAA |
| Manufacturer Product Class | Back to Back |
| Country of Origin | United States |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Warranty | |
|---|---|
| Limited Warranty | 5 Year |
|
